Use the Add/Remove Ports window to add and remove ports from user-defined port groups.
To access this window, select the left-panel Port Groups tab. Expand the User-Defined Port Groups folder and select a port group. From this window you can:
- Select the Add/Remove Ports button in the right-panel Ports tab.
- Right-click a Port Group in the left-panel and select Add/Remove Ports.
- Default Group — Port Membership
- This list displays all the device groups, devices, and port groups in the current domain. Select the ports you want to add to the port group. You can select individual ports, devices, or groups of ports.
- Other Groups — Port Membership
- This field displays all the ports currently defined for the port group. Select the port you want to remove from the port group.
- Add/Move To Button
- Select Add/Move To and select the port group to add the ports selected in the Default Group — Port Membership list to the Other Groups — Port Membership list.
- Remove Button
- Select Remove to remove the ports selected in the Other Groups — Port Membership list from the port group.
- Remove All Button
- Select Remove All to remove all the ports in the Other Groups — Port Membership list.
For information on related help topics:
